IBCA – mazaná olejovou mlhou
|
Typ |
Vřeteno |
Max. délka upnutí L1 |
Max. otáčky min-1 |
Hřídel |
Řemenice |
Max. šířka řemenu R |
O |
Max. Æ brousicího kotouče 45 m.s-1 |
||||
|
D |
L |
d |
d1 |
d1 |
d1 |
L2 |
||||||
|
IBCA 5 17 60 |
50 |
175 |
160 |
60 000 |
8,5 |
8 |
16* |
31 |
14,5 |
15 |
85 |
d1 |
|
IBCA 5 17 50 |
50 000 |
10,5 |
8 |
19,2* |
32 |
14,5 |
15 |
85 |
17 |
|||
|
IBCA 5 17 40 |
40 000 |
15,5 |
10,5 |
16 |
51 |
24 |
25 |
85 |
21 |
|||
|
IBCA 5 25 40 |
50 |
250 |
235 |
40 000 |
15,5 |
10,5 |
16 |
51 |
24 |
25 |
120 |
21 |
|
IBCA 6 20 32 |
60 |
200 |
185 |
32 000 |
18,5 |
11 |
19,5 |
61 |
29 |
30 |
100 |
26 |
|
IBCA 7 22 25 |
70 |
225 |
210 |
25 000 |
23 |
14 |
25 |
63 |
29 |
30 |
110 |
34 |
|
IBCA 8 22 25 |
80 |
225 |
210 |
25 000 |
23 |
14 |
25 |
63 |
29 |
30 |
110 |
34 |
|
IBCA 6 25 32 |
60 70 70 |
250 |
235 |
32 000 |
18,5 |
11 |
19,5 |
61 |
29 |
30 |
120 |
26 |
|
IBCA 7 25 25 |
25 000 |
23 |
14 |
25 |
63 |
29 |
30 |
120 |
34 |
|||
|
IBCA 7 25 20 |
20 000 |
28 |
15 |
32 |
62 |
28 |
30 |
120 |
42 |
|||
|
IBCA 8 25 25 |
80 |
250 |
235 |
25 000 |
23 |
14 |
25 |
63 |
29 |
30 |
120 |
34 |
|
IBCA 8 25 20 |
20 000 |
28 |
15 |
32 |
62 |
28 |
30 |
120 |
42 |
|||
|
IBCA 8 25 16 |
16 000 |
33 |
16 |
40 |
72 |
33 |
40 |
120 |
54 |
|||
|
IBCA 10 30 2 |
100 |
300 |
280 |
20 000 |
28 |
15 |
32 |
62 |
28 |
30 |
150 |
42 |
|
IBCA 10 30 16 |
16 000 |
33 |
16 |
40 |
72 |
33 |
40 |
150 |
54 |
|||
|
IBCA 10 30 12 |
12 500 |
38 |
20 |
50 |
87 |
40 |
60 |
150 |
68 |
|||
|
IBCA 10 35 16 |
100 |
350 |
330 |
16 000 |
33 |
16 |
40 |
72 |
33 |
40 |
150 |
54 |
|
IBCA 10 35 12 |
12 500 |
38 |
20 |
50 |
87 |
40 |
60 |
150 |
68 |
|||
|
IBCA 10 35 10 |
10 000 |
43 |
21 |
63 |
87 |
40 |
60 |
150 |
85 |
|||
|
IBCA 12 35 8 |
125 |
350 |
330 |
8 000 |
53 |
23 |
78 |
108 |
51 |
70 |
150 |
107 |
